Jinay Metals is a manufacturer and supplier of high-quality Mild Steel Flanges based in Dubai, UAE and known to be precise in engineering and high performance. Our firm has a good reputation of quality and reliability and offers a wide variety of Mild Steel flanges that are applicable in different industrial purposes such as oil and gas, construction, and power generation. The flanges of our product are made of high-grade materials that result in durability, strength, and corrosion resistance. Jinay Metals is concerned with providing affordable solutions to its customers under a time-sensitive service to satisfy international customers.
Mild Steel Flanges have iron with a carbon level of 0.05 to 0.25 with little traces of components such as manganese, silicon, and other minor constituents. This composition offers good ductility, welds and also machinability. Its mechanical properties are tensile strength ranging between 400 and 550 MPa, yield strength approximately 250 MPa and elongation 2030 percent, based on grade and heat treatment. Mild Steel Flanges are tough and structurally sound, so they are good to use in moderate pressure in different industrial and construction setting.
| Specifications | MS |
|---|---|
| Size Ranges | From 1/2 inch (i.e. 15 NB) upto 48 inch (i.e. 1200NB) |
| JIS Standards | 5 K, 10K, 16K, 20 K, 30K, 40K, 63 K |
| Flange Face Type | FF, RF, LMF, SMF, RTJ, LJF. |
| Pressure Classes | Cl 150, Class 300, Cl. 400, 600, Class 900, Cl 1500 and 2500 |
| Standards | ASME | BS | DIN | ANSI | GOST | EN Flange |
| UNI/ DIN / EN Standard | 6Bar, 10 Bar, 16Bar, 25 Bar, 40Bar |
| Composition | Content |
|---|---|
| Sulfur, S | ≤ 0.050 % |
| Iron, Fe | 98.81 – 99.26 % (as remainder) |
| Carbon, C | 0.14 – 0.20 % |
| Manganese, Mn | 0.60 – 0.90 % |
| Phosphorous, P | ≤ 0.040 % |
| Mechanical Properties | Metric | Imperial |
|---|---|---|
| Hardness, Knoop (Converted from Brinell hardness) | 145 | 145 |
| Hardness, Brinell | 126 | 126 |
| Tensile Strength, Yield | 370 MPa | 53700 psi |
| Elongation at Break (In 50 mm) | 15.0 % | 15.0 % |
| Poissons Ratio | 0.290 | 0.290 |
| Reduction of Area | 40.0 % | 40.0 % |
| Machinability (Based on AISI 1212 steel. as 100% machinability) | 70 % | 70 % |
| Modulus of Elasticity | 205 GPa | 29700 ksi |
| Bulk Modulus | 140 GPa | 20300 ksi |
| Shear Modulus | 80.0 GPa | 11600 ksi |
| Hardness, Vickers (Converted from Brinell hardness) | 131 | 131 |
| Hardness, Rockwell B (Converted from Brinell hardness) | 71 | 71 |
| Tensile Strength, Ultimate | 440 MPa | 63800 psi |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Mild Steel Flanges from Jinay Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Jinay Metals providing reliable and high-performance Alloy 20 Flanges tailored to meet your specific operational and project requirements.
Jinay Metals, one of the leading suppliers of Mild Steel Flanges in Dubai, UAE, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide Mild Steel Flanges to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Mild Steel Flanges are greatly applied in the industries that demand effective and hardy connection systems of piping systems at economical costs. Their application is generally in oil and gas, water supply, construction, power generation, shipbuilding and chemical processing industries. These flanges are very perfect in connecting pipes, valves, pumps and other equipment to come up with reliable and leak free connections. Mild Steel Flanges are also preferred in terms of structural and mechanical uses due to their high machinability and weldability. They are versatile, strong, and affordable, which means that they can work in low- or medium-pressure conditions in the context of different types of industries.
