Home > Inconel > Inconel 625 Forged Fittings
Jinay Metals, a leading manufacturer and supplier located in Dubai, UAE, specializes in crafting high-quality Inconel 625 Forged Fittings that are designed to excel in tough environments. These fittings are celebrated for their incredible strength, resistance to corrosion, and durability, even when faced with extreme pressure and temperature. With a commitment to advanced technology and rigorous quality standards, Jinay Metals guarantees that each fitting offers outstanding performance and a long lifespan. Inconel 625 Forged Fittings are perfect for applications in the chemical processing, marine, and aerospace sectors, where reliability, precision, and resistance to harsh substances are crucial.
The composition of Inconel 625 Forged Fittings primarily includes nickel, chromium, and molybdenum, along with niobium and iron to boost strength and corrosion resistance. This unique blend gives the alloy exceptional resistance to pitting, crevice corrosion, and oxidation in both oxidizing and reducing environments. On the mechanical side, Inconel 625 showcases high tensile and yield strength, excellent fatigue resistance, and remarkable stability across a broad temperature range. It retains its toughness even in cryogenic conditions, ensuring dependable performance in demanding situations.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Inconel 625 Forged Fittings from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Inconel 625 Forged Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Inconel 625 Forged Fittings to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Inconel 625 Forged Fittings find extensive use in various industries, including marine engineering, oil and gas, aerospace, chemical processing, and power generation. They are particularly suited for components that come into contact with seawater, high pressure, and corrosive chemicals, such as piping systems, heat exchangers, and turbine exhaust systems. In the aerospace field, they are utilized in jet engine components and exhaust ducts, thanks to their ability to endure extreme thermal and mechanical stress. Their exceptional corrosion resistance and long-lasting durability make them essential for critical and high-performance industrial applications.
