Jinay Metals, a prominent manufacturer and supplier located in Dubai, UAE, is known for crafting top-notch Inconel Forged Fittings that stand out for their remarkable strength and resistance to corrosion. These fittings are designed to perform reliably even in the harshest environments, making them perfect for industries that demand durability and precision. With state-of-the-art manufacturing facilities and rigorous quality control measures, Jinay Metals guarantees that every product adheres to international standards. Their Inconel Forged Fittings are tailored for seamless integration into piping systems, delivering exceptional performance under high pressure and temperature conditions.
These fittings are primarily made from nickel, chromium, and iron, with small amounts of molybdenum, niobium, and titanium added in. This special blend gives them excellent resistance to oxidation, carburization, and chloride-ion stress corrosion cracking. On the mechanical side, these fittings boast high tensile strength, good fatigue resistance, and impressive stability across a broad temperature range. Their outstanding thermal properties and durability make them perfect for aggressive environments where traditional materials might not hold up.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Inconel Forged Fittings from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Inconel Forged Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Inconel Forged Fittings to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Inconel Forged Fittings find their place in various industries, including oil and gas, petrochemical, aerospace, marine, and power generation. They play a crucial role in applications that involve high pressure and temperature, such as heat exchangers, boilers, chemical processing systems, and turbine components. Their ability to withstand corrosion in acidic and high-temperature settings ensures they deliver long-lasting performance and safety. Moreover, these fittings are also used in offshore and subsea systems, where resistance to seawater and oxidation is vital, providing reliability and efficiency in challenging industrial operations.
