Jinay Metals, located in Dubai, UAE, stands out as a top manufacturer and supplier of Nickel Alloy 200 Forged Fittings. These fittings are highly regarded for their remarkable corrosion resistance, impressive strength, and dependable performance in tough industrial settings. Each fitting is meticulously crafted to adhere to international quality standards, making them perfect for applications in chemical processing, marine, and power generation sectors. Jinay Metals provides a wide array of forged fittings, including elbows, tees, couplings, and unions, all designed for superior fit and durability. Thanks to cutting-edge technology and rigorous quality checks, Jinay Metals ensures that their Nickel Alloy 200 Forged Fittings deliver long-lasting service and consistent performance.
The Nickel Alloy 200 Forged Fittings are made up of 99.6% pure wrought nickel, which gives them excellent resistance to alkalis, neutral salts, and reducing agents. This alloy not only boasts superior thermal and electrical conductivity but also offers outstanding ductility and toughness. Mechanically, these fittings show high tensile and yield strength, maintaining excellent performance across a broad temperature range. Their good weldability and fabricability make them ideal for creating strong connections in piping systems that face corrosive and high-temperature conditions.
| Dimension Specification | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
|---|---|
| Thread | NPT, BSPT, BSPP |
| Type | DN15-DN1200 |
| End | Threaded, Welding, JIC |
| Pressure Rating | Threaded end-2000lb/ 3000lb/ 6000lbs Pipe Fittings Socket-weld end-3000/ 6000/ 9000lbs Pipe Fittings |
| Connection | Welding |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Crosses, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows – Female-Female, Male-Female, Male-Male, Union, Nipples, Couplings, Plugs Fittings |
| Application |
|
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Nickel Alloy 200 Forged Fittings from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Nickel Alloy 200 Forged Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Nickel Alloy 200 Forged Fittings to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
You’ll find Nickel Alloy 200 Forged Fittings used across various industries, including chemical processing, marine engineering, power generation, food processing, and electronics. They’re particularly well-suited for applications involving caustic soda, alkalis, and acidic solutions, as well as for equipment like heat exchangers, condensers, and pressure vessels. These fittings provide exceptional corrosion resistance in both neutral and alkaline environments while maintaining their mechanical integrity under thermal stress. With their durability, purity, and strength, Nickel Alloy 200 Forged Fittings are the go-to choice for critical operations that demand long-term reliability and outstanding corrosion performance.
