Jinay Metals is an established producer and distributor of 16Mo3 flanges in Dubai, UAE with high-quality, highly engineered products. As the experts in alloy steel solutions, we offer durable high performance flanges which are suitable in boilers, pressure vessels and heat exchangers. The company enjoys a good reputation in the different industries thanks to its adherence to quality, affordable prices, and delivery in a timely manner. Our products are of international quality that is reliable and strong when it comes to the application in demanding industry.
16Mo3 flanges are manufactured from chromium-molybdenum alloy steel developed for high-temperature purposes. The typical chemical composition consists of Carbon (0.12–0.20%), Manganese (0.40–0.90%), Silicon (0.35%), Molybdenum (0.25–0.35%), Phosphorus (0.025% max), and Sulphur (0.010% max). These elements provide strength, toughness and ability to withstand heat and corrosion. The mechanical properties include a tensile strength of 450–600 MPa, yield strength of 280 MPa, and elongation of approximately 22%. 16Mo3 flanges perform very well in high-pressure and high-temperature situations, such as boilers and heat exchangers.
| Specifications | 16Mo3 Flanges |
|---|---|
| Coating | Anti-rust Paint/ Zinc Plated/ Oil Black Paint/ Yellow Transparent/ Cold and Hot Dip Galvanized |
| Manufacturer of | Forged/ Threaded/ Screwed / Plate |
| Manufacturer Length | NPS 1⁄₂” Inch To NPS 48” Inch |
| Face Type | RTJ/ RF/ FF |
| Schedule Chart | SCH 5S To XXS. |
| Vishal Steel Manufacturer Belbow Types | Weld Neck/ Socket Weld/ Threaded/ Reducing/ Lap Joint/ Blind/ Slip On |
| Forging Methods | Forging & Casting, Rolling & Cutting |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Application | Bitumen upgraders Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids. |
| JIS Standard | 5K/ 10K/ 16K 20K/ 30K/ 40K/ 63K |
| Flange Test | Hydrostatic testing machine/ UI trasonic flaw detector/ X-ray detector/ Direct-reading Spectrograph/ Magnetic particle detector |
| Supporting Material | Gasket/ Ring Joint/ Flange Bolts |
| Production Technique | Forged/ Heat treated and machined |
| Packing | Plywood Pallet And Plywood Box |
| Brand | Vishal Steel |
| Productivity | 800 ton per month |
| Transportation | Ocean And Air |
| Supply Ability | 700 Ton Per Month |
| Flange Equipment | Pushing Machine/ electric bevelling machine/ Press machine/ Bending machine/ Sand-blasting machine etc |
| Element | Percentage % | Element | Percentage % |
| P | 0.025 | V | – |
| S | 0.010 | Al | – |
| Cr | 0.030 | N | 0.012 |
| Mo | 0.25/0.35 | Cu | 0.30 |
| C | 0.12/0.20 | Ni | 0.30 |
| Si | 0.35 | Nb | – |
| Mn | 0.40/0.90 | Ti | – |
| 16Mo3 Flanges | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation in 100-150 mm(%) | Maximum Thickness (mm) | Elongation in 16 mm(%) |
| 440-590 | 220-275 | 19 | 250 | 24 |
|
DIN,WNr |
BS |
UNI |
ISO |
DIN | UNS |
|
16Mo3 |
240 |
16Mo3 |
P26 |
1.5415 | K11562 |
|
243 |
TS26 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing 16Mo3 Flanges from Jinay Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Jinay Metals providing reliable and high-performance 16Mo3 Flanges tailored to meet your specific operational and project requirements.
Jinay Metals, one of the leading suppliers of 16Mo3 Flanges in Dubai, UAE, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
| Normal Pipe Size | DN |
|---|---|
| 1/2 | 15 |
| 3/4 | 20 |
| 1 | 25 |
| 1 1/4 | 32 |
| 1 1/2 | 40 |
| 2 | 50 |
| 2 1/2 | 65 |
| 3 | 80 |
| 4 | 100 |
| Flanges Size inches | Flanges Size millimeter | Outer Diameter (O.D.) inches | Outer Diameter (O.D.) millimeter | Inner Diameter (I.D.) inches | Inner Diameter (I.D.) millimeter | Ø B.H.C. In inches | Ø B.H.C. In millimeter | Ø B.H. inches | Ø B.H. millimeter | # B.H. | Thickness inches | Thickness millimeter | Weight lbs | Weight Kilogram |
| 8.0 | 200 | 13.39 | 340 | 8.72 | 221.50 | 11.61 | 295 | 0.870 | 22 | 12 | 1.020 | 26 | 21.0 | 9.5 |
| 10.0 | 250 | 15.94 | 405 | 10.88 | 276.40 | 13.97 | 355 | 1.020 | 26 | 12 | 1.140 | 29 | 31.0 | 14.1 |
| 12.0 | 300 | 18.11 | 460 | 12.88 | 327.20 | 16.14 | 410 | 1.020 | 26 | 12 | 1.260 | 32 | 42.7 | 19.4 |
| 14.0 | 350 | 20.47 | 520 | 14.19 | 360.40 | 18.50 | 470 | 1.020 | 26 | 16 | 1.380 | 35 | 62.3 | 28.3 |
| 15.0 | 400 | 22.83 | 580 | 16.19 | 411.20 | 20.67 | 525 | 1.180 | 30 | 16 | 1.500 | 38 | 80.5 | 36.5 |
| 17.0 | 450 | 25.20 | 640 | 18.19 | 462.00 | 23.03 | 585 | 1.180 | 30 | 20 | 1.650 | 42 | 110.3 | 50.1 |
| 19.0 | 500 | 28.15 | 715 | 20.19 | 512.80 | 25.59 | 650 | 1.300 | 33 | 20 | 1.810 | 46 | 141.5 | 64.2 |
| 24.0 | 600 | 33.07 | 840 | 24.19 | 614.40 | 30.32 | 770 | 1.420 | 36 | 20 | 2.050 | 52 | 213.5 | 96.9 |
Yes, we provide 16Mo3 Flanges to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
The 16Mo3 flanges are commonly employed in industries with high temperature and pressure resistance. Their high mechanical strength combined with resistance to corrosion makes them suitable in boilers, heat exchangers, pressure vessel and steam pipelines. They are also applied in the power generation, petrochemical, oil and gas, and refinery industries in connecting pipes and providing leak proof joints under extreme conditions using 16Mo3 alloy steel. They can also be used as a industrial furnace, chemical plant, thermal processing systems and these flanges are very durable, efficient and have long service life in harsh usage.
