Renowned for providing high-end industrial flange solutions that satisfy international standards, Jinay Metals is a top manufacturer and supplier of SWISS VSM Flanges in Dubai, United Arab Emirates. Jinay Metals provides a wide variety of SWISS VSM Flanges made for various industrial applications, all with a strong emphasis on precision engineering, robustness, and dependability. To guarantee exceptional performance and resistance to corrosion, our products are made from premium materials and put through rigorous quality testing. Supported by cutting-edge technology and industry knowledge, Jinay Metals keeps providing excellent and satisfied customer service to clients throughout the United Arab Emirates and beyond.
The alloy may be a stainless grade (e.g., 304/316 family) or duplex/super-duplex (e.g., UNS S31803/22Cr-5Ni-3Mo) with C ≤ 0.03-0.03 %, Si ≤ 1 %, Mn ≤ 2 %, P ≤ 0.03 %, S ≤ 0.02 %, Cr approx. 21-26 %, Ni approx. 4.5-8 % in duplex, Mo approx. 3-5 % in higher alloys. In duplex steel form, yield strength (0.2% offset) is ~ 550 MPa (80 ksi) minimum, tensile strength ~ 700 MPa, with elongation ~ 15-25 % minimum
| Size: | 1/2″NB TO 24″NB IN |
| Class: | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS DIN Standard ND-6,10, 16, 25, 40 Etc. |
| Materials: | Monel : Grade: Monel 400, Monel K500, Monel R-405 Nickel : Grade: Nickel 200, Nickel 201 Inconel : Grade: Inconel 600, Inconel 601, Inconel 625, Inconel 718 Incoloy : Grade: Incoloy 800, Inconel 800H, 800HT Hastalloy : Grade: Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X Titanium : Grade: Gr1, Gr2, Gr3, Gr5, Gr7, Gr11 Stainless Steel : Grade: ASTM A182 F202, F304/304L/304H, F316/316L, F316H, F316TI, F310, F321, F904L Carbon Steel : Grade: ASTM A105/A105N, A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, A694 F42, F46, F48, F50, F52, F56, F60, F65, F70, A516.60, 65, 70 (Spectacle Blind Flange, Spacer Ring/Spade Flange), Steel RST37.2, C22.8 Duplex Steel: Grade: ASTM / ASME A/SA 182 UNS F44, F45, F51, F53, F55, F60, F61 Alloy Steel: Grade : ASTM A182 F1, F5, F9, F11, F22, F91 |
| Value Added Service: | CNC Machine, Customized Flanges |
| Coating/Surface Treatment: | Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Blind Flanges from Jinay Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Jinay Metals providing reliable and high-performance SWISS VSM FLANGE tailored to meet your specific operational and project requirements.
| Size Of Flanges | T | D1 | C | B | Hole | F | G |
| NW16CF | 7,6 | 34 | 27 | 4,4 / M4 | 6 | 21,5 | 18,3 |
| NW35CF | 12,7 | 70 | 58,7 | 6,7 / M6 | 6 | 48,35 | 41,9 |
| NW50CF | 15.8 | 85,6 | 72,4 | 8,4 / M8 | 8 | 61,8 | 55,6 |
| NW63CF | 17,5 | 113,5 | 92,1 | 8,4 / M8 | 8 | 82,55 | 77,2 |
| NW100CF | 19,9 | 151,6 | 130,3 | 8,4 / M8 | 16 | 120,7 | 115,3 |
| NW150CF | 22,3 | 202,4 | 181 | 8,4 / M8 | 20 | 171,5 | 166,1 |
| NW200CF | 24,6 | 253,2 | 231,8 | 8,4 / M8 | 24 | 222,35 | 216,9 |
| NW250CF | 26 | 306 | 284 | 8,4 / M8 | 32 | 273,2 | 267 |
| NW300CF | 28,4 | 355,6 | 325,4 | 10,5 / M10 | 30 | 313,5 | 307,3 |
| NW350CF | 28,5 | 419,1 | 388,9 | 10,5 / M10 | 36 | 376,9 | 370,7 |
Jinay Metals, one of the leading suppliers of SWISS VSM FLANGE in Dubai, UAE, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide SWISS VSM FLANGE to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
In industrial piping systems, the SWISS VSM Flange is frequently used to safely connect pipes, valves, pumps, and other equipment. It makes assembly, disassembly, and maintenance simple and guarantees leak-proof joints. Oil and gas, chemical processing, water treatment, pharmaceuticals, and power generation are examples of common applications. It is appropriate for high-pressure and high-temperature operations due to its exceptional precision, durability, and resistance to corrosion. The flange ensures system compatibility by supporting multiple connection standards. In order to ensure operational safety and a long service life in demanding environments, industries that demand dependable sealing, mechanical strength, and effective fluid transfer favor SWISS VSM Flanges.
