Based in Dubai, United Arab Emirates, Jinay Metals is a well-known producer and supplier of ANSI/ASA B16.5 flanges, known for providing superior industrial piping solutions for a range of industries. A wide variety of flanges made for performance, dependability, and durability are offered by Jinay Metals, which is dedicated to precision engineering and international standards. Our products cater to the needs of the oil & gas, petrochemical, power, and construction industries. Jinay Metals is a reputable brand for high-quality ANSI/ASA B16.5 flanges in the UAE and international markets thanks to its state-of-the-art manufacturing facilities, stringent quality control, and timely delivery.
ANSI / ASA B16.5 flanges are typically manufactured from materials such as carbon steel, stainless steel, and alloy steel, ensuring excellent strength and corrosion resistance. The composition varies by grade but generally includes iron, carbon, chromium, nickel, and molybdenum for enhanced durability. Mechanically, these flanges offer tensile strength ranging from 400 to 700 MPa, yield strength between 200 to 450 MPa, and elongation of 20–30%. Designed to withstand high pressure and temperature, ANSI / ASA B16.5 flanges ensure secure, leak-proof connections in critical piping systems.
| Specifications | ANSI / ASA B16.5 Flanges |
|---|---|
| ANSI / ASA B16.5 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Production technique | Forged, Heat treated and machined |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS JIS Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Specialized manufacturer of | DIN 2566 en 1092 1 Pn16 Flange DIN 2566 pn16 Rtj Flange ANSI / ASA B16.5 Sorf Flange ANSI / ASA B16.5 Table Flanges DIN 2566 pn10 ANSI / ASA B16.5 Large Diameter Flange ANSI / ASA B16.5 Threaded Flanges ANSI / ASA B16.5 Blind Flanges ANSI / ASA B16.5 Plate Flanges ANSI / ASA B16.5 Weld Neck Flanges ANSI / ASA B16.5 Loose Flanges ANSI / ASA B16.5 Orifice Flanges ANSI / ASA B16.5 Slip-On Flanges ANSI / ASA B16.5 Lap Joint Flanges ANSI / ASA B16.5 Socketweld Flanges ANSI / ASA B16.5 AS 4087 Water Flanges |
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | West Europe /Indian / USA / Japan / Korean |
| Key markets and industries for ANSI / ASA B16.5 Flange | Nuclear power (mostly seamless). Heavy oil refineries. Bitumen upgraders. Petrochemicals and acids. |
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, Oman etc |
| ANSI / ASA B16.5 Flanges Application | To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical, Gas, Shipbuilding,Metallurgy, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Blind Flanges from Jinay Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Jinay Metals providing reliable and high-performance DIN FLANGE PN6-PN40 tailored to meet your specific operational and project requirements.
ANSI/ASME/ASA B16.5 300lb/sq.in. Flange BLIND-RF | |||||||
ø | D | b | g | k | Holes | l | Kg. |
1/2″ | 95,2 | 14,3 | 34,9 | 66,7 | 4 | 15,9 | 0,700 |
3/4″ | 117,5 | 15,9 | 42,9 | 82,5 | 4 | 19,0 | 1,200 |
1″ | 123,8 | 17,5 | 50,8 | 88,9 | 4 | 19,0 | 1,500 |
1 1/4″ | 133,3 | 19,0 | 63,5 | 98,4 | 4 | 19,0 | 2,000 |
1 1/2″ | 155,6 | 20,6 | 73,0 | 114,3 | 4 | 22,2 | 2,900 |
2″ | 165,1 | 22,2 | 92,1 | 127,0 | 8 | 19,0 | 3,400 |
2 1/2″ | 190,5 | 25,4 | 104,8 | 149,2 | 8 | 22,2 | 5,100 |
3″ | 209,5 | 28,6 | 127,0 | 168,3 | 8 | 22,2 | 7,000 |
3 1/2″ | 228,6 | 30,2 | 139,7 | 184,1 | 8 | 22,2 | 8,900 |
4″ | 254,0 | 31,7 | 157,2 | 200,0 | 8 | 22,2 | 11,800 |
5″ | 279,4 | 34,9 | 185,7 | 234,9 | 8 | 22,2 | 15,500 |
6″ | 317,5 | 36,5 | 215,9 | 269,9 | 12 | 22,2 | 21,300 |
8″ | 381,0 | 41,3 | 269,9 | 330,2 | 12 | 25,4 | 35,200 |
10″ | 444,5 | 47,6 | 323,8 | 387,3 | 16 | 28,6 | 57,000 |
12″ | 520,7 | 50,8 | 381,0 | 450,8 | 16 | 31,7 | 82,000 |
14″ | 584,2 | 54,0 | 412,7 | 514,3 | 20 | 31,7 | 106,000 |
16″ | 647,7 | 57,1 | 469,9 | 571,5 | 20 | 34,9 | 140,000 |
18″ | 711,2 | 60,3 | 533,4 | 628,6 | 24 | 34,9 | 178,000 |
20″ | 774,7 | 63,5 | 584,2 | 685,8 | 24 | 34,9 | 223,000 |
22″ | 838,2 | 66,7 | 641,2 | 742,9 | 24 | 41,3 | 270,000 |
24″ | 914,4 | 69,8 | 692,1 | 812,8 | 24 | 41,3 | 345,000 |
Jinay Metals, one of the leading suppliers of ANSI / ASA B16.5 FLANGE in Dubai, UAE, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide API FLANGE to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
In order to create a safe piping system, ANSI/ASA B16.5 flanges are frequently used to join pipes, valves, pumps, and other equipment. They are crucial in sectors like oil and gas, petrochemical, power generation, water treatment, shipbuilding, and chemical processing that demand resistance to high pressure and high temperature. These flanges make it simple to assemble, disassemble, inspect, and maintain pipelines. Boiler systems, industrial piping networks, offshore platforms, and refineries are examples of common applications. ANSI/ASA B16.5 flanges guarantee dependable, leak-proof connections in a variety of industrial and mechanical operations thanks to their precise design and strong performance.
