Based in Dubai, United Arab Emirates, Jinay Metals is a well-known manufacturer and supplier of Australian flanges, known for providing high-end industrial flange solutions for a variety of industries. Jinay Metals offers a large selection of Australian flanges made to satisfy the needs of the petrochemical, construction, marine, and oil and gas industries. The company places a high priority on precision engineering, durability, and international standards. The business has established a reputation for excellence and dependability thanks to its cutting-edge technology, strict quality control, and on-time delivery. For customers looking for top-notch flange solutions in the UAE and elsewhere, Jinay Metals remains the reliable partner.
Australian flanges are precision-engineered components made primarily from high-quality carbon steel, stainless steel, or alloy steel. Their composition typically includes elements like iron, carbon, chromium, nickel, and molybdenum, ensuring excellent strength and corrosion resistance. Mechanically, Australian flanges exhibit high tensile strength, toughness, and durability, capable of withstanding high pressure and temperature variations. They maintain dimensional accuracy and integrity under stress, providing leak-proof connections in pipelines. These flanges meet AS/NZS, ANSI, and DIN standards, ensuring reliable performance across industrial, petrochemical, and marine applications.
| Material Specification Of : | Australian Flange And Sabs 1123 Pipe Flanges |
|---|---|
| Standard Cover : | pressure ratings & temperature ratings, materials, marking, dimensions, weight, tolerances, testing |
| Contact Faces | RTJ (Ring Type Joint), FF (Flat Face), RF (Raised Face), T/G (Tongue And Groove ), M/F (Male And Female) |
| Marking Standard | Name of Manufacturer Schedule Type of Flange Facing Nominal Pipe Size Pressure Class ASME B16 Designation |
| Bolt Type | high strength bolts medium strength bolts low strength bolts |
| Surface Finish | smooth, concentric serrated, stock |
| Gaskets Types | Full Face Gasket Flat Ring Gasket Metallic Ring Gakset |
| Advantages Of Pipe Flange | Used to Connect Pipe System Easy Repair Pipe System Assembled Without Welding |
| Size Chart | Normal Pipe Size 1/2 to NPS 24″ |
| Materials | Stainless Steel (Grade 304/L, 316/L), Carbon Steel (ASTM A105 And ASTM A350), Alloy Steel (ASTM A182), Mild Steel, Duplex Steel, Pressure Vessel Steel, Titanium, Super Duplex Steel, Nickel Alloy, Monel, Inconel, Hastelloy, Copper Nickel, Cast Iron, Wrought Iron. |
| Thickness | Normal Pipe Size ≤ 18 |
| Bore Diameter | Normal Pipe ≤ 10 |
| Flanges Standards | EN 1092-1, JIS, ASME B16.5, ASME B16.47 type A, UNI, DIN |
| Pressure Rating | Class 150 To Class 2500 |
| High Temperature | Above 200°C (400°F) For Class 150 Or Above 400°C (750°F) |
| Low Temperature | Above -29 Degree C (−20°F) |
| Common Types Of Flanges: | Slip On (SORF), Weld Neck (WNRF), Blind (BLRF), Lap Joint (Loose), Threaded (NPT), Socket-Weld (SWRF) |
| Special Types Of Flanges : | Nipoflange, Elboflange, Latroflange, Swivel Flange, Expanding Flange, Reducing Flange, Weldoflange |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Blind Flanges from Jinay Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Jinay Metals providing reliable and high-performance AUSTRALIAN FLANGES tailored to meet your specific operational and project requirements.
Nominal Pipe Bore 15 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600/3 | 80millimeter | 55millimeter | 4 | M10 | 11millimeter | 10millimeter |
SABS1123-1000/3 | 95millimeter | 65millimeter | 4 | M12 | 14millimeter | 10millimeter |
SABS1123-1600/3 | 95millimeter | 65millimeter | 4 | M12 | 14millimeter | 10millimeter |
SABS1123-2500/3 | 95millimeter | 65millimeter | 4 | M12 | 14millimeter | 14millimeter |
SABS1123-4000/3 | 95millimeter | 65millimeter | 4 | M12 | 14millimeter | 14millimeter |
Nominal Pipe Bore 20 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 90millimeter | 65millimeter | 4 | M10 | 11millimeter | 10millimeter |
SABS1123-1000 | 105millimeter | 75millimeter | 4 | M12 | 14millimeter | 10millimeter |
SABS1123-1600 | 105millimeter | 75millimeter | 4 | M12 | 14millimeter | 10millimeter |
SABS1123-2500 | 105millimeter | 75millimeter | 4 | M12 | 14millimeter | 14millimeter |
SABS1123-4000 | 105millimeter | 75millimeter | 4 | M12 | 14millimeter | 14millimeter |
Nominal Pipe Bore 25 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 100millimeter | 75millimeter | 4 | M10 | 11millimeter | 10millimeter |
SABS1123-1000 | 115millimeter | 85millimeter | 4 | M12 | 14millimeter | 10millimeter |
SABS1123-1600 | 115millimeter | 85millimeter | 4 | M12 | 14millimeter | 10millimeter |
SABS1123-2500 | 115millimeter | 85millimeter | 4 | M12 | 14millimeter | 16millimeter |
SABS1123-4000 | 115millimeter | 85millimeter | 4 | M12 | 14millimeter | 16millimeter |
Nominal Pipe Bore 32 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 120millimeter | 90mm | 4 | M12 | 14mm | 10mm |
SABS1123-1000 | 140mm | 100mm | 4 | M16 | 18mm | 10mm |
SABS1123-1600 | 140mm | 100mm | 4 | M16 | 18mm | 10mm |
SABS1123-2500 | 140mm | 100mm | 4 | M16 | 18mm | 18mm |
SABS1123-4000 | 140mm | 100mm | 4 | M16 | 18mm | 18mm |
Nominal Pipe Bore 40 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 130mm | 100mm | 4 | M12 | 14mm | 10mm |
SABS1123-1000 | 150mm | 110mm | 4 | M16 | 18mm | 10mm |
SABS1123-1600 | 150mm | 110mm | 4 | M16 | 18mm | 10mm |
SABS1123-2500 | 150mm | 110mm | 4 | M16 | 18mm | 20mm |
SABS1123-4000 | 150mm | 110mm | 4 | M16 | 18mm | 20mm |
Nominal Pipe Bore 50 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 140mm | 110mm | 4 | M12 | 14mm | 10mm |
SABS1123-1000 | 165mm | 125mm | 4 | M16 | 18mm | 10mm |
SABS1123-1600 | 165mm | 125mm | 4 | M16 | 18mm | 12mm |
SABS1123-2500 | 165mm | 125mm | 4 | M16 | 18mm | 20mm |
SABS1123-4000 | 165mm | 125mm | 4 | M16 | 18mm | 20mm |
Nominal Pipe Bore 65 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 160mm | 130mm | 4 | M12 | 14mm | 10mm |
SABS1123-1000 | 185mm | 145mm | 4 | M16 | 18mm | 12mm |
SABS1123-1600 | 185mm | 145mm | 4 | M16 | 18mm | 12mm |
SABS1123-2500 | 185mm | 145mm | 8 | M16 | 18mm | 22mm |
SABS1123-4000 | 185mm | 145mm | 8 | M16 | 18mm | 22mm |
Nominal Pipe Bore 80 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 190mm | 150mm | 4 | M16 | 18mm | 10mm |
SABS1123-1000 | 200mm | 160mm | 8 | M16 | 18mm | 12mm |
SABS1123-1600 | 200mm | 160mm | 8 | M16 | 18mm | 14mm |
SABS1123-2500 | 200mm | 160mm | 8 | M16 | 18mm | 22mm |
SABS1123-4000 | 200millimeter | 160millimeter | 8 | M16 | 18millimeter | 22millimeter |
Nominal Pipe Bore100 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 210millimeter | 170millimeter | 4 | M16 | 18millimeter | 10millimeter |
SABS1123-1000 | 220millimeter | 180millimeter | 8 | M16 | 18millimeter | 12millimeter |
SABS1123-1600 | 220millimeter | 180millimeter | 8 | M16 | 18millimeter | 14millimeter |
SABS1123-2500 | 235millimeter | 190millimeter | 8 | M20 | 22millimeter | 25millimeter |
SABS1123-4000 | 235millimeter | 190millimeter | 8 | M20 | 22millimeter | 25millimeter |
Nominal Pipe Bore150 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 240millimeter | 200millimeter | 8 | M16 | 18millimeter | 12millimeter |
SABS1123-1000 | 250millimeter | 210millimeter | 8 | M16 | 18millimeter | 14millimeter |
SABS1123-1600 | 250millimeter | 210millimeter | 8 | M16 | 18millimeter | 16millimeter |
SABS1123-2500 | 270millimeter | 220millimeter | 8 | M24 | 26millimeter | 28millimeter |
SABS1123-4000 | 270millimeter | 220millimeter | 8 | M24 | 26mm | 28mm |
Nominal Pipe Bore200 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 265mm | 225mm | 8 | M16 | 18mm | 12mm |
SABS1123-1000 | 285mm | 240mm | 8 | M20 | 22mm | 16mm |
SABS1123-1600 | 285mm | 240mm | 8 | M20 | 22mm | 18mm |
SABS1123-2500 | 300mm | 250mm | 8 | M24 | 26mm | 30mm |
SABS1123-4000 | 300mm | 250mm | 8 | M24 | 26mm | 30mm |
Nominal Pipe Bore250 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 320mm | 280mm | 8 | M16 | 18mm | 14mm |
SABS1123-1000 | 340mm | 295mm | 8 | M20 | 22mm | 18mm |
SABS1123-1600 | 340mm | 295mm | 12 | M20 | 22mm | 22mm |
SABS1123-2500 | 360mm | 310mm | 12 | M24 | 26mm | 28mm |
SABS1123-4000 | 375mm | 320mm | 12 | M24 | 26mm | 32mm |
Nominal Pipe Bore300 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 375mm | 335mm | 12 | M16 | 18mm | 16mm |
SABS1123-1000 | 395mm | 350mm | 12 | M20 | 22mm | 20mm |
SABS1123-1600 | 405mm | 355mm | 12 | M24 | 26mm | 25mm |
SABS1123-2500 | 425mm | 370mm | 12 | M24 | 26mm | 30mm |
SABS1123-4000 | 450mm | 385mm | 12 | M30 | 33mm | 38mm |
Nominal Pipe Bore500 | Diameter Of Flange | PCD | Bolts Of Flanges | Size Of Bolt | Size Of Hole | Thickness Of Flanges |
SABS1123-600 | 645mm | 600mm | 20 | M20 | 22mm | 25mm |
SABS1123-1000 | 670mm | 620mm | 20 | M24 | 26mm | 32mm |
SABS1123-1600 | 715mm | 650mm | 20 | M30 | 33mm | 40mm |
SABS1123-2500 | 730mm | 660mm | 20 | M30 | 33mm | 50mm |
SABS1123-4000 | 755mm | 670mm | 20 | M39 | 39mm | 70mm |
Jinay Metals, one of the leading suppliers of AUSTRALIAN FLANGES in Dubai, UAE, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide AUSTRALIAN FLANGES to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Industries that need safe and effective piping connections frequently use Australian flanges. For connecting pipes, valves, pumps, and other equipment, they are crucial in the petrochemical, oil and gas, power generation, water treatment, and marine industries. Because of their sturdy design, pipeline systems are simple to assemble, disassemble, and maintain. In order to ensure strong and leak-proof joints, Australian flanges are also utilized in high-pressure and high-temperature settings. Refineries, offshore platforms, chemical plants, and HVAC systems are examples of common applications. These flanges guarantee safe, dependable, and long-lasting performance in infrastructure and industrial projects by adhering to AS/NZS and international standards.
