Based in Dubai, United Arab Emirates, Jinay Metals is a well-known manufacturer and supplier that specializes in premium EN 1092-1 flanges in the PN6–PN40 range. Dedicated to precision engineering and global standards, Jinay Metals provides robust and dependable flanges for a variety of industrial uses, such as the petrochemical, water treatment, oil, and gas industries. To guarantee excellent performance, durability, and safety, the company combines sophisticated manufacturing processes with strict quality control. In the UAE and beyond, Jinay Metals has made a name for itself as a reliable partner for customers looking for premium EN 1092-1 flanges due to its prompt delivery and affordable prices.
EN 1092-1 flanges, ranging from PN6 to PN40, are standardized steel flanges widely used in piping systems. They are primarily made from carbon steel (e.g., S235, S275, S355) or stainless steel (e.g., 304, 316), ensuring compatibility with various media. Mechanically, they offer high tensile strength, yield strength, and toughness suitable for pressure ratings from 6 to 40 bar. The flanges exhibit excellent hardness, impact resistance, and durability under temperature variations. Surface finishes and dimensional tolerances comply with EN 1092-1, ensuring reliable sealing, structural integrity, and long-term performance in industrial applications.
| Material Specification Of : | EN 1092-1 Flange |
|---|---|
| Marking Standard | Name of Manufacturer Schedule Type of Flange Facing Nominal Pipe Size Pressure Class ASME B16 Designation |
| Bolt Type | high strength bolts medium strength bolts low strength bolts |
| European Standard Flanges | JIS B2220 Flanges (5k to 30k) and KS1503 flanges |
| Russian-Standard Flanges | GOST 12820 / 12821-80, DIN, UNI, EN 1092-1 |
| South African Standard Flanges | SANSflanges And SABS flanges |
| Surface Finish | smooth, concentric serrated, stock |
| Standard Cover : | pressure ratings & temperature ratings, materials, marking, dimensions, weight, tolerances, testing |
| Contact Faces | RTJ (Ring Type Joint), FF (Flat Face), RF (Raised Face), T/G (Tongue And Groove ), M/F (Male And Female) |
| Size Chart | Normal Pipe Size 1/2 to NPS 24″ |
| Materials | Stainless Steel (Grade 304/L, 316/L), Carbon Steel (ASTM A105 And ASTM A350), Alloy Steel (ASTM A182), Mild Steel, Duplex Steel, Pressure Vessel Steel, Titanium, Super Duplex Steel, Nickel Alloy, Monel, Inconel, Hastelloy, Copper Nickel, Cast Iron, Wrought Iron. |
| Thickness | Normal Pipe Size ≤ 18 |
| Bore Diameter | Normal Pipe ≤ 10 |
| Flanges Standards | EN 1092-1, JIS, ASME B16.5, ASME B16.47 type A, UNI, DIN |
| Pressure Rating | Class 150 To Class 2500 |
| High Temperature | Above 200°C (400°F) For Class 150 Or Above 400°C (750°F) |
| Low Temperature | Above -29 Degree C (−20°F) |
| Common Types Of Flanges: | Slip On (SORF), Weld Neck (WNRF), Blind (BLRF), Lap Joint (Loose), Threaded (NPT), Socket-Weld (SWRF) |
| Special Types Of Flanges : | Nipoflange, Elboflange, Latroflange, Swivel Flanges, Expanding Flanges, Reducing Flanges, Weldoflanges |
| Gaskets Types | Full Face Gasket Flat Ring Gasket Metallic Ring Gakset |
| Advantages Of Pipe Flanges | Used to Connect Pipe System Easy Repair Pipe System Assembled Without Welding |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Blind Flanges from Jinay Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Jinay Metals providing reliable and high-performance EN 1092-1 FLANGE PN6-PN40 tailored to meet your specific operational and project requirements.
| Flange DN Sizes | Pipe | Flange | Screws | Flange Weight In KG | ||||
| d1 | k | D | b | d2 | Bolt holes | KG | ||
| 200 | 219,1 | 221,5 | 295 | 340 | 24 | 22 | 8 | 9,244 |
| 250 | 273,0 | 276,5 | 350 | 395 | 26 | 22 | 12 | 11,788 |
| 300 | 323,9 | 327,5 | 400 | 445 | 26 | 22 | 12 | 13,578 |
| 350 | 355,6 | 359,5 | 460 | 505 | 30 | 22 | 16 | 21,766 |
| 400 | 406,4 | 411,0 | 515 | 565 | 32 | 26 | 16 | 27,436 |
| 450 | 457,2 | 462,0 | 565 | 615 | 36 | 26 | 20 | 33,470 |
| 500 | 508,0 | 513,5 | 620 | 670 | 38 | 26 | 20 | 40,103 |
| 600 | 610,0 | 616,5 | 725 | 780 | 42 | 30 | 20 | 54,297 |
| 700 | 711,0 | 714,2 | 840 | 895 | 50 | 30 | 24 | 82,777 |
| 800 | 813,0 | 815,8 | 950 | 1015 | 56 | 33 | 24 | 116,534 |
| 900 | 914,0 | 917,4 | 1050 | 1115 | 62 | 33 | 28 | 141,425 |
| 1000 | 1016,0 | 1019,0 | 1160 | 1230 | 70 | 36 | 28 | 188,561 |
Jinay Metals, one of the leading suppliers of EN 1092-1 FLANGE PN6-PN40 in Dubai, UAE, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide EN 1092-1 FLANGE PN6-PN40 to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Flanges EN 1092-1 Standardized circular flanges PN6–PN40 are used in piping systems to join equipment, pumps, valves, and pipes. They are extensively used in the HVAC, chemical, petrochemical, oil and gas, water treatment, and power generation sectors. They guarantee dependable sealing at a range of operating pressures and temperatures and come in pressure ratings ranging from PN6 to PN40. These flanges make it simple to assemble, disassemble, inspect, and maintain pipelines. Both low-pressure and high-pressure systems can use them, and they work well with threaded or welded connections. They are necessary for the safe and effective transportation of fluids because of their robustness and uniformity.
