Jinay Metals is a reputable manufacturer and supplier located in Dubai, UAE, known for its top-notch Stainless Steel Forged Fittings. The company has built a solid reputation thanks to its precision engineering, high-quality materials, and commitment to international standards. These fittings are crafted to ensure leak-proof and durable connections in piping systems, even when faced with high pressure and temperature. With state-of-the-art manufacturing facilities and a strong emphasis on quality assurance, Jinay Metals provides Stainless Steel Forged Fittings that cater to a variety of industries, including petrochemical, oil & gas, power generation, and marine engineering.
The Stainless Steel Forged Fittings are constructed from premium stainless steel, which includes chromium (18–20%), nickel (8–12%), and trace amounts of molybdenum, carbon, and manganese. This unique blend gives them outstanding corrosion resistance, impressive tensile strength (around 515 MPa), and good ductility. They can handle extreme temperatures and pressures while maintaining excellent performance and mechanical integrity. Available in various grades like SS 304, 304L, 316, 316L, and 321, these fittings offer options tailored to different industrial needs.
| Specifications | ASTM A403/ ASME SA403 |
|---|---|
| Size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
| Stainless Steel Forged Fittings | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel Forged Fittings from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Stainless Steel Forged Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Stainless Steel Forged Fittings to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
These fittings are commonly found in piping systems that demand strong, reliable, and corrosion-resistant connections. You’ll often see them in refineries, chemical processing plants, power stations, and offshore installations. They play a crucial role in connecting, controlling, or redirecting fluid flow in high-pressure systems. Available in forms such as elbows, tees, couplings, unions, and plugs, they are also essential in water treatment facilities, food processing, and pharmaceutical industries, ensuring efficient performance, durability, and safety in critical service environments.
