Jinay Metals, a well-respected manufacturer and supplier located in Dubai, UAE, is all about crafting top-notch Monel Pipe Fittings that excel in tough, corrosive, and high-temperature settings. These pipes are celebrated for their remarkable resistance to seawater, acids, and alkalis, making them perfect for demanding industrial tasks. Thanks to cutting-edge manufacturing methods and strict quality controls, Jinay Metals guarantees that each Monel Pipe boasts outstanding strength, durability, and precision. Their products find a home in various sectors, including marine, chemical, and power generation, where reliability and longevity are crucial.
Monel Pipe Fittings mainly consist of nickel (up to 67%) and copper, along with trace amounts of iron, manganese, carbon, and silicon. This special blend gives them exceptional corrosion resistance across a variety of environments, including both acidic and alkaline solutions. On the mechanical side, Monel Pipes deliver high tensile and yield strength, impressive ductility, and solid toughness, even in freezing temperatures. They also show remarkable resistance to stress-corrosion cracking and pitting, making them suitable for high-pressure and high-temperature scenarios.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : Seamless Butt Weld Fittings : 1/2″ – 10″ | Welded Butt Weld Fittings : 1/2″ – 48″
Schedule : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type : Seamless / ERW / Welded / Fabricated
Thickness :20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc.
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| Monel 400 | 63.0- 70.00 max | 2.50 max | 0.3 max | 2.00 max | 0.50 max | Remainder | – | – | 0.024 max |
| Monel K500 | 63.0 min | 05 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.35 – 0.85 | 0.010 max |
| Grade | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness (HRb) |
|---|---|---|---|---|
| 400 | 75 to 90 | 25 to 50 | 60 to 35 | 60 to 80 |
| K500 | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15,000 , MPa – 790 | 20 % | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel Pipe Fittings from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Monel Pipe Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Monel Pipe Fittingsto match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
These Monel Pipe Fittings are a go-to choice in industries like marine engineering, chemical processing, oil and gas, and hydrocarbon refining. They’re perfect for heat exchangers, condensers, evaporators, and piping systems that come into contact with seawater or harsh chemicals. In the marine sector, Monel Pipes are utilized for seawater piping and pump shafts due to their outstanding resistance to saltwater corrosion. Their durability, reliability, and ability to maintain strength under extreme conditions make them a top pick for critical and long-lasting industrial applications.
