Jinay Metals, a well-respected manufacturer and supplier located in Dubai, UAE, specializes in top-quality Monel 400 Pipes that are renowned for their outstanding corrosion resistance and impressive strength. These pipes are designed to excel in tough and corrosive settings, such as seawater, chemical processing facilities, and marine applications. Jinay Metals takes pride in ensuring that every Monel 400 Pipe is crafted with precision and adheres strictly to international standards, which guarantees their durability, dimensional accuracy, and long-lasting performance. Their products are widely recognized for their exceptional reliability even under extreme temperature and pressure conditions.
Monel 400 Pipes Fitting are made up of about 67% nickel and 23% copper, along with trace amounts of iron, manganese, silicon, and carbon. This unique blend gives them remarkable resistance to seawater, acids, and alkalis, while also providing solid mechanical strength. The alloy boasts high tensile and yield strength, excellent ductility, and impressive resistance to stress-corrosion cracking. Monel 400 maintains its toughness and stability across a broad temperature range, making it suitable for both cryogenic and high-temperature applications.
Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79
Size Seamless 1/2″ – 10″ , Welded 1/2″ – 48″
Type (Seamless & 100% X-Ray Welded, Fabricated)
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Grade Monel K500 Pipe Fittings UNS (N05500), DIN (2.4375)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 115000 , MPa – 790 | Psi – 160000 , MPa – 1100 | 20 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Monel 400 Pipes Fitting from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Monel 400 Pipes Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Monel 400 Pipes to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
These Monel 400 Pipes Fitting find extensive use in various industries, including marine engineering, chemical processing, oil and gas, and power generation. They are perfect for applications such as heat exchangers, condensers, evaporators, seawater piping, and pump shafts. In the chemical sector, they are particularly valuable for handling sulfuric and hydrofluoric acids due to their exceptional corrosion resistance. With their durability, ease of welding, and ability to maintain mechanical integrity in challenging environments, Monel 400 Pipes are the go-to choice for long-lasting and high-performance industrial systems.
