Home > Monel 400Flanges
A well-known producer and supplier with headquarters in Dubai, United Arab Emirates, Jinay Metals specializes in premium Monel 400 flanges to meet a range of industrial demands. Their products, which meet international standards and are renowned for their precision engineering and durability, guarantee dependable performance in demanding applications. Jinay Metals is dedicated to providing high-quality flanges that are resistant to pressure, heat, and corrosion by combining sophisticated manufacturing processes with strict quality control. The company has established itself as a reliable partner for Monel 400 flange requirements in the UAE and beyond by providing customized solutions, fast delivery, and competitive pricing to industries like oil and gas, chemical, and marine.
Monel flanges are primarily composed of nickel (about 60–70%) and copper (28–34%), with small amounts of iron, manganese, and silicon. This alloy offers exceptional corrosion resistance, especially in seawater and acidic environments. Mechanically, Monel flanges exhibit high tensile strength, good fatigue resistance, and excellent toughness at both high and low temperatures. They maintain dimensional stability under stress and are resistant to work hardening. Their combination of strength, durability, and corrosion resistance makes Monel flanges ideal for chemical processing, marine, and high-temperature applications.
| Specification | ASTM B564 / ASME SB564 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 400 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276 |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Blind Flanges from Jinay Metals ensures unmatched quality and long-lasting performance. These Flanges are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise. Jinay Metals provides reliable and high-performance Monel 400 Flanges tailored to meet your specific operational and project requirements.
Jinay Metals, one of the leading suppliers of Monel 400 Flanges in Dubai, UAE, offers a wide selection of high-quality flanges suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide Monel 400 Flanges to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored flanges solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Many industries that demand exceptional strength and resistance to corrosion use Monel 400 flanges. Their resistance to saltwater, acids, and alkalis makes them perfect for use in seawater applications, chemical processing, and marine environments. In the petroleum, power generation, and aerospace industries, where resistance to high temperatures and pressures is essential, these flanges are also utilized. For long-term dependability and durability, Monel 400 flanges are appropriate for heat exchangers, pumps, valves, and pipe systems. They are favored in extremely corrosive and demanding industrial applications due to their non-magnetic qualities and resilience to harsh environments.
