Jinay Metals, a top-notch manufacturer and supplier located in Dubai, UAE, specializes in high-quality Duplex Steel S31803 Pipe Fittings that are known for their outstanding strength, durability, and resistance to corrosion. These fittings are designed to excel in tough environments, blending the best features of both austenitic and ferritic stainless steels. With a commitment to precision manufacturing, rigorous quality control, and compliance with international standards, Jinay Metals delivers products that promise longevity and reliability. Duplex Steel S31803 Pipe Fittings are perfect for sectors like oil and gas, petrochemical, marine, and power generation, where strength and resistance to corrosion are essential.
These fittings are made up of about 22% chromium, 5–6% nickel, and 3% molybdenum, with added nitrogen to boost their strength and corrosion resistance. This well-balanced composition results in a dual-phase microstructure of ferrite and austenite, giving them twice the yield strength compared to standard austenitic stainless steels. The alloy is highly resistant to pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. Plus, it maintains good weldability, toughness, and stability even under high-pressure and high-temperature conditions.
| ASTM A815 WPS S31803 Pipe Fittings Standard Dimensions | ASME/ ANSI B16.9, ASME B16.28, MSS-SP-43, BS1560, BS4504, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
|---|---|
| Specifications | ASTM A815 / ASME SA815 |
| Duplex Steel S31803 Elbow | Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO |
| A815 WPS S31803 Pipe Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| ASTM A815 WPS 31803 Pipe fittings Thread | NPT, BSPT, BSPP |
| Duplex Steel S31803 Forged Fittings Types | Seamless / Welded / ERW / Fabricated UNS S31803 DSS Pipe Fittings |
| Duplex Steel UNS S31803 Pipe Fittings size | Seamless ASTM A815 WPS S31803 Butt Weld Fittings: 1/2″ – 10″ Welded SA 815 S31803 Butt Weld Fittings: 1/2″ – 48″ |
| Duplex Steel S31803 Forged Fittings Working Pressure | Threaded end-2000lb/ 3000lb/ 6000lbs Duplex Stainless Steel S31803 Pipe Fittings Socket-weld end-3000/ 6000/ 9000lbs Duplex Stainless Steel UNS S31803 Pipe Fittings |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Stainless Duplex S31803 Pipe Fittings |
| Duplex Steel WPS S31803 Pipe Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| SA 815 S31803 Pipe Fittings Size Range | 1/2″ NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| Specialized manufacturer of | 90º Elbows, 45 degree Elbows, Tee, Cross, Couplings, Caps, Reducers, Inserts, Equal Tees & Reducing Tees, Nipples, Forged Pipe Fittings, Socket Weld & Threaded, 90° & 45° Elbows – Male-Male, Male-Female, Female-Female, Couplings, Union |
| Duplex Steel S31803 Pipe Fittings End |
|
| Material Test Certificates (MTC) for Duplex UNS S31803 Pipe Fittings as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
|---|---|---|---|---|---|---|---|---|---|
| 1.0 | 0.03 | 0.02 | 2.0 | 3.0 – 3.5 | 22.0 – 23.0 | 0.03 | 4.5 – 6.5 | 0.14 – 0.2 | Bal |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Duplex Steel S31803 Pipe Fittings from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Duplex Steel S31803 Pipe Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Duplex Steel S31803 Pipe Fittings to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Duplex Steel S31803 Pipe Fittings find extensive use in chemical processing, marine engineering, desalination plants, and offshore oil and gas operations. They are particularly suited for heat exchangers, pressure vessels, condensers, and pipelines that face corrosive and saline environments. In the petrochemical and power sectors, their ability to endure stress and corrosion in harsh conditions makes them highly valued. With their impressive combination of strength, corrosion resistance, and durability, Duplex Steel S31803 Pipe Fittings are the go-to choice for demanding industrial applications.
