Jinay Metals is a leading manufacturer and supplier of high-quality Carbon Steel P265GH Pipe Fittings in Dubai, UAE. With a strong reputation for precision engineering and reliable performance, we provide fittings designed to withstand high pressure and elevated temperatures, making them ideal for power generation, oil & gas, and industrial applications. Our products meet global standards, ensuring excellent durability, corrosion resistance, and long service life. Backed by advanced manufacturing facilities and strict quality control, Jinay Metals is committed to delivering superior piping solutions that meet the diverse needs of clients across the UAE and international markets.
Carbon Steel P265GH Pipe Fittings are made from a non-alloy steel grade primarily composed of carbon (up to 0.20%), manganese (0.80–1.40%), silicon (up to 0.40%), phosphorus (max 0.025%), and sulfur (max 0.020%). These elements provide strength, toughness, and good weldability. Mechanically, P265GH offers a minimum tensile strength of 410–530 MPa and a minimum yield strength of 265 MPa. It also provides excellent high-temperature resistance, making it suitable for pressure vessels and high-pressure pipelines. The material maintains consistent performance under elevated thermal and mechanical stress.
| P265GH Carbon Steel Pipe Fittings size | P265GH Seamless Butt Weld Fittings : 1/2″ – 10″ P265GH Welded Butt Weld Fittings : 1/2″ – 48″ |
|---|---|
| CS P265GH Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1800, BS10 |
| P265GH Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| P265GH Buttweld Pipe FittingsType | DN15-DN1200 |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A234 Gr P265GH Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A234 P265GH Buttweld Fitting |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| P265GH Carbon Steel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| EN 10253-1 P265GH Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | CS 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Element | % by mass | Element | % by mass |
| Carbon (C) | ≤0.20 | Silicon (Si) | ≤0.40 |
| Manganese (Mn) | 0.80 to 1.40 | Phosphorous (P) (maximum) | 0.025 |
| Sulphur (S) (maximum) | 0.015 | Aluminium (Al) | <=0.020 |
| Nitrogen (N) | <=0.012 | Chromium (Cr) | <=0.30 |
| Copper (Cu) | <=0.30 | Molybdenum (Mo) | <=0.08 |
| Niobium (Nb) | <=0.020 | Nickel (Ni) | <=0.30 |
| Titanium (Ti) (maximum) | 0.03 | Vanadium (Vi) | <=0.02 |
| Nominal thickness (millimeter): | to 100 | 100 – 150 | 150 – 250 |
| Rm – Tensile strength (MPa) (+N) | 410-530 | 400-530 | 390-530 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel P265GH Pipe Fittings from Jinay Metals ensures unmatched quality and long-lasting performance. These pipes are engineered for superior corrosion resistance, strength, and precision, making them ideal for a wide range of industrial applications. With a strong focus on customer satisfaction, timely delivery, and technical expertise, Jinay Metals provides reliable and high-grade stainless steel solutions tailored to meet your specific project requirements.
Jinay Metals, one of the leading suppliers of Carbon Steel P265GH Pipe Fittings in Dubai, UAE, offers a wide selection of high-quality pipes and tubes suitable for various industrial applications. With an extensive inventory, reliable sourcing, and a strong commitment to quality, service, and timely delivery, Jinay Metals has established itself as a trusted name for premium stainless steel products across the UAE.
Yes, we provide custom sizes of Carbon Steel P265GH Pipe Fittings to match your exact project requirements. At Jinay Metals, our team is dedicated to delivering tailored piping and tubing solutions that ensure precision and reliability. For more information or personalized assistance, reach out to us at sales@jinaymetals.ae.
Carbon Steel P265GH Pipe Fittings are widely used in industries requiring strong, heat-resistant, and durable piping components. They are commonly applied in boilers, heat exchangers, and pressure vessels due to their excellent performance at elevated temperatures. The oil and gas sector utilizes these fittings for high-pressure transmission lines, refinery units, and petrochemical processing. They are also used in power plants, chemical industries, fertilizer units, and industrial steam pipelines. Their reliable mechanical strength and corrosion resistance make them ideal for systems involving high thermal and mechanical stress, ensuring safe and efficient operation across various critical applications.
